Atlas Copco
TEX 14 / 15 Rivet Buster
Atlas Copco TEX 14 and TEX 15 rivet busters are available with an open pistol handle or a classic D-handle. Select the exact handle and cylinder configuration for your quote.
Designed for rivet removal, concrete chipping and breaking, demolition and bridge maintenance. A teasing throttle supports precise control, and a stepped cylinder provides added safety.
Manufacturer specifications below are published at 6.2 bar (90 psi). Claw couplings are not included; the handbook identifies Atlas Copco Standard coupling 9001 0005 01.
The photographs are the manufacturer’s TEX 14/15 family illustrations of the pistol and D-handle styles, not separate photographs of all four configurations.
Complete tool: TEX 14 PistolTool part # 8461 0250 16
Jumbo shank; short (8-inch) cylinder; open pistol handle, outside trigger
Your BEST price is just a call away.
Adds the complete tool shown above—not an individual replacement part. Add more tools to build one quote request, then review your quote list.
1-800-241-9669Need help with a model or part? Talk to Mining Auger & Tool Works.
Technical Specs
| Specification | TEX 14 Pistol | TEX 14 D | TEX 15 Pistol | TEX 15 D |
|---|---|---|---|---|
| Chuck / shank size | Jumbo | Jumbo | Jumbo | Jumbo |
| Cylinder | Short (8") | Short (8") | Long (11") | Long (11") |
| Handle type | Open | D | Open | D |
| Trigger type | Outside | Inside | Outside | Inside |
| Weight (kg) | 13.7 | 14.1 | 15 | 15.4 |
| Length (mm) | 584 | 600 | 660 | 676 |
| Air consumption (l/s) | 21 | 21 | 21 | 21 |
| Impact rate (blows/min) | 900 | 900 | 720 | 720 |
| Impact energy (joules) | 47.5 | 59.6 | 63.1 | 72.1 |
| Vibration, 3 axes (ISO 20643), m/s² | 12.6 | 12.3 | 13.3 | 14.3 |
| Guaranteed sound power (2000/14/EC), Lw dB(A) | 105 | 105 | 105 | 105 |
| Sound pressure (ISO 11203), Lp at 1 m, dB(A) | 93 | 93 | 93 | 93 |
Specification TEX 14 Pistol
- Chuck / shank size
- Jumbo
- Cylinder
- Short (8")
- Handle type
- Open
- Trigger type
- Outside
- Weight (kg)
- 13.7
- Length (mm)
- 584
- Air consumption (l/s)
- 21
- Impact rate (blows/min)
- 900
- Impact energy (joules)
- 47.5
- Vibration, 3 axes (ISO 20643), m/s²
- 12.6
- Guaranteed sound power (2000/14/EC), Lw dB(A)
- 105
- Sound pressure (ISO 11203), Lp at 1 m, dB(A)
- 93
Specification TEX 14 D
- Chuck / shank size
- Jumbo
- Cylinder
- Short (8")
- Handle type
- D
- Trigger type
- Inside
- Weight (kg)
- 14.1
- Length (mm)
- 600
- Air consumption (l/s)
- 21
- Impact rate (blows/min)
- 900
- Impact energy (joules)
- 59.6
- Vibration, 3 axes (ISO 20643), m/s²
- 12.3
- Guaranteed sound power (2000/14/EC), Lw dB(A)
- 105
- Sound pressure (ISO 11203), Lp at 1 m, dB(A)
- 93
Specification TEX 15 Pistol
- Chuck / shank size
- Jumbo
- Cylinder
- Long (11")
- Handle type
- Open
- Trigger type
- Outside
- Weight (kg)
- 15
- Length (mm)
- 660
- Air consumption (l/s)
- 21
- Impact rate (blows/min)
- 720
- Impact energy (joules)
- 63.1
- Vibration, 3 axes (ISO 20643), m/s²
- 13.3
- Guaranteed sound power (2000/14/EC), Lw dB(A)
- 105
- Sound pressure (ISO 11203), Lp at 1 m, dB(A)
- 93
Specification TEX 15 D
- Chuck / shank size
- Jumbo
- Cylinder
- Long (11")
- Handle type
- D
- Trigger type
- Inside
- Weight (kg)
- 15.4
- Length (mm)
- 676
- Air consumption (l/s)
- 21
- Impact rate (blows/min)
- 720
- Impact energy (joules)
- 72.1
- Vibration, 3 axes (ISO 20643), m/s²
- 14.3
- Guaranteed sound power (2000/14/EC), Lw dB(A)
- 105
- Sound pressure (ISO 11203), Lp at 1 m, dB(A)
- 93
Complete tool configurations
Match the model, shank and part number. These are complete tools, not replacement parts.
| Model | Shank / Details | Part Number | Quote |
|---|---|---|---|
| TEX 14 Pistol | Jumbo shank; short (8-inch) cylinder; open pistol handle, outside trigger | 8461 0250 16 | |
| TEX 14 D | Jumbo shank; short (8-inch) cylinder; D-handle, inside trigger | 8461 0250 17 | |
| TEX 15 Pistol | Jumbo shank; long (11-inch) cylinder; open pistol handle, outside trigger | 8461 0250 18 | |
| TEX 15 D | Jumbo shank; long (11-inch) cylinder; D-handle, inside trigger | 8461 0250 19 |
Accessory Tools
Match the shank, collar and size to your tool. Each button adds that individual accessory to your quote list.
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)10" | jb-10rc |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)8" | jb-p03-8 |
| Under-collar length (inches)12" | jb-p03-12 |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)12" | jb-12p |
| Under-collar length (inches)18" | jb-18p |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)12" | jb-12c |
| Under-collar length (inches)18" | jb-18c |
| Dimensions / Details | Jumbo 11X |
|---|---|
| Under-collar length (inches)10" | jb-rip |
Longer lengths available for most tools. Call 800-241-9669 for help matching your tool.
